Description


Features
  • Pilot operated, normally open or normally closed
  • Snubber slows disc closing speed to protect system against water hammer damage more effectively than other techniques
  • Pressure spike due to water hammer is reduced to a point eliminating the need for suppressors or other controls in most water systems


Solenoid Enclosures
  • Standard: RedHat II - Watertight, Types 1, 2, 3, 3S, 4, and 4X; RedHat - Type I.
  • Optional: RedHat II - Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9; RedHat - Explosionproof and Raintight, Types 3, 7, and 9.
Read more
Manuals (1)
Specs
Application:
Heating
Size:
1"
Voltage:
24v
Position:
Normally Open
Flow Capacity (Cv):
11.5 Cv
Flow type:
High Flow
Hertz:
60
Wattage:
6.1/F (AC)
22.6/F (DC)
Pressure Differential:
5 psi (Minimum)
125 psi (Max DC)
150 psi (Max AC)
Max Fluid Temp:
180°F (AC)
150°F (DC)
Material:
Brass
Features:
Pilot Operated
Slow Closing
Height:
6.53"
Length:
3-3/4"
Width:
3.16"
×
