Description
The Eliminator Submersible High Head Effluent pumps are designed to handle 3/4" solids. Shut-off at 50', heavy-duty cast iron housing, volute and vortex impeller, thermal overload protection and 2" FNPT discharge.
  • Handles liquids with 3/4" solids.
  • Cast iron pump housing, impeller and volute with protective epoxy coating for corrosion and rust resistance.
  • Oil filled motor housing for lifetime mechanical seal and bearing lubrication and efficient heat dissipation.
  • Stainless steel screws, bolts, handle, and seal assembly.
  • Mechanical seals (stainless steel spring, nitrile parts, carbon and ceramic faces) with secondary exclusion seal.
  • High speed (3450 RPM), 1 HP, ball bearing motor with terminal overload protection for high head operation.
  • Permanent split capacitor design.
  • Capacitor and power cord connections isolated from oil filled housing for ease of field maintenance.
  • Dynamically balanced two-vane vortex impeller with pump-out vanes to keep solids away from seal for less seal and bearing wear.
  • 2" Discharge

Read more
Manuals (2)
Specs
Horse Power:
1
Type:
Manual
Voltage:
240v
208v
Shutoff Head (ft.):
81
Solids Size:
3/4"
Discharge:
2"
Phase:
3
Cord Length:
20 ft
×
