4 Zone Switching Relay w/ Priority Zoom
  • 360° View

4 Zone Switching Relay w/ Priority

SKU:SR504-EXP-4

Brand: Taco

Taco
Qty Price
$188.95
/ each
$365.70 / box (2 units x $182.85)
In Stock! Ships in 24-48 Hours
(72 Available)
3

Specs

Zones:
?
4
Width (Inches): 10-1/4"
Height (Inches): 6.75
Depth (Inches): 2-3/4"
Amperage:
?
20
Power Control Plugs: 1
Application: Zoning
Power Method: 120 VAC Input
Voltage:
?
120 VAC

Description for Taco SR504-EXP-4

Taco Switching Relays combine clearly-labeled PC board layouts with advanced features that allow you to completely customize your system. External indicator lights give you instant diagnostic feedback, making service calls or new installation start-ups a snap. All switching relays are UL listed, use standard "ice cube" replaceable relays and are compatible with conventional and programmable thermostats. For larger jobs, switching relays can be expanded up to 20 zones with priority. Any expandable switching relay can also interface with the Boiler Reset Control and Injection Mixing Add-On Power Controls. Mix-and-match as needed to customize the system.

Features include:

  • External Indicator Lights
  • Switchable Priority
  • Simplified Wiring
  • Fully Enclosed Snap-Out Relays
  • Compact Design
  • Fuse Protected
  • 100% Factory Tested
  • Isolated End Switch
  • Contractor Friendly PC Board Layout
  • Universal Thermostat Compatibility
  • UL and CSA Approved24 Volt Power Input or Output Terminal
  • Extended 3 Year Warranty
  • Made in the USA
