Main product image of Modulating Temperature Controller, 55 F to 175 F, with analog and relay output

Hover image to zoom

Modulating Temperature Controller, 55 F to 175 F, with analog and relay output

Name: Modulating Temperature Controller, 55 F to 175 F, with analog and relay output
Brand: Honeywell
SKU: T991A1350
Price: 334.99 USD
Availability: OutOfStock

Brand:

Honeywell

SKU:

T991A1350

Rating:

(0)

Q&A:

(0)

Modulating Temperature Controller, 55 F to 175 F, with analog and relay output

Hover image to zoom

T991A1350 has been discontinued

This product has been discontinued

MANUALS (1)

Install Instructions

Product Highlights

–

24V, 24 VAC to 30 VAC

175°F Max Temp

55°F Min Temp

Gray

5-7/8"

2-3/16" Depth

Description

–

For modulating control of water or air temperature in ducts, tanks and similar applications.

Features

Fast response models (for duct mounting) have coiled sensing element giving at least four times faster response than standard models
Ambient temperature compensated for the case and tubing
Sensing element capillary tubing allows remote mounting of sensing element
Setpoint may be read and adjusted through cover
Throttling dial inside case adjusts proportional throttling range.

Specifications

Description: Modulating Temperature Controller, 55 F to 175 F
Application: Provide modulating control of water or air temperature in ducts or tanks
Type: Modulating Remote bulb
Output Type: Analog and Relay
Analog Output: One 135 Ohm Potentiometer
Output: 1 SPST
Voltage: 24 Vac to 30 Vac
Frequency: 60 Hz
Frequency: 50 Hz
Color: Gray
Dimensions (in.): 5-5/8 in. high x 2 in. wide x 2-1/4 in. deep
Sensor Element: Copper averaging element
Number of Sensor Inputs: 1
Capillary Length (ft): 24 ft
Bulb Size (in.): 1/2 in. diameter x 4-3/16 in. long
Setpoint Temperature Range (F): 55F to 175 F
Maximum Operating Temperature (F): 200 F
Throttling Range (F): 3.5 F to 36 F

Specs

–

Application:	Remote Bulb Temperature
Output:	Analog One 135 Ohm Potentiometer
Voltage:	24V 24 VAC to 30 VAC
Hertz:	60 50
Color:	Gray
Height:	5-7/8"
Width:	4-1/8"
Depth (Inches):	2-3/16"
Sensor Type:	Copper Averaging Element
Sensor Inputs:	1
Capillary Length:	24 ft.
Bulb Size:	7/64" x 24 Ft
Min Temp (F):	55°F
Temperature Range (F):	55°F to 175°F
Max Temp (F):	175°F
Max Operating Temp:	200°F
Throttling Range:	3.5°F to 36°F
