Description
Note: Product Title reflects this boiler's IBR Net Output Rating

Product Features
  • 84% AFUE – DOE 2021 Compliant!
  • Residential Cast Iron Boiler for Hot Water Heating Systems
  • Fully Packaged and Ready to Install!
  • Cast Iron Sections – Factory Tested and Assembled with Steel Push Nipples
  • Natural Draft Chimney Venting (see manual for specific venting instructions)
  • Low Profile Design: Ideal for Installations with Low Ceilings
Standard Equipment
  • Hydrostat IC integrated boiler control provides dependable spark ignition, low water cut-off and boiler reset for energy savings! Control also features TWO circulator outputs allowing for DHW priority/heating zone.
  • Circulator
  • Temperature-Pressure Gauge
  • 30 PSI Safety Relief Valve (Optional 50 PSI Safety Relief Valve Available)
  • Standard Safety Controls Including Flame Rollout Shut-off Switch and Vent Safety Switch
  • Drain Valve
  • Automatic Vent Damper
  • Integral Draft Diverter
Hide Description
Specs
Fuel Type:

Natural Gas

BTU Input:

195000

IBR Rating:

139000

DOE Rating:

160000

Features:

EI/Spark Ignition

Efficiency:

84.4%

Number of Sections:

7

Vent Size:

7"

Height (Inches):

31.375"

Width (Inches):

26"

Depth (Inches):

26-5/8"

Weight (lbs):

575 lbs

System Type:

Hydronic (Water)

Vent Type:

Atmospheric

Material:

Cast Iron

Boiler Type:

Packaged

Warranty:

1 Year Boiler Limited Lifetime Cast Iron Sections

×
