120 Pint Dehumidifier

Overview The Broan 120 Pint Dehumidifier delivers superior indoor air quality with it's MERV 13 filtration and dedicated humidity control. With a 120 pints per day removal capacity this unit is well suited for medium to larger homes. The system design provides excellent energy efficiency to provide humidity control for large spaces.

Product Features

• Removes up to 120 pints of water per day
• Provides up to 3,000 sq. ft. of coverage to provide humidity control to larger homes
• MERV 13 filtration installed standard to provide superior air filtration
• Discharge duct can be installed in either a horizontal or vertical orientation providing additional install flexibility
• Humidity control be done easily using either our DEH 3000 digital controller that is mounted in the interior space or with the
• DEH 3000 R digital controller with its remote sensor that is mounted in the interior space where the humidity level needs to be managed
• Included fresh air inlet provides the option for fresh outdoor air to be ducted to the unit

Product Specifications

• Water Removal Capacity @ 80F & 60% RH (pints/day): 121
• Efficiency (pints/kWh): 6.1
• Energy Factor (liters/kWh): 2.9
• Power (Watts) @ 80°F & 60% RH: 840
• Airflow (CFM) @ 0.0 in. WG: 350
• Airflow (CFM) @ 0.2 in. WG: 285
• Airflow (CFM) @ 0.4 in. WG: 210
• Filtration: MERV 13
• Optional Fresh Air Duct: 6" Round
• Inlet Duct Size: 10" Round
• Outlet Duct Size: 10" Round
• Operating Current (Amps): 7.3
• Power Cord: 9' Type B Plug
• Integrated Circuit Breaker: Yes
• Refrigerant Type: R410A
• Refrigerant Qty (oz.): 26
• Drain Connection: 3/4" Threaded Female NPT
• Coverage (sq. ft): 3000
• Product Weight (Lbs): 91
• Manufacturer Warranty: 6 Year
• Product Dimensions: 14.375"W x 21"H x 32.1875"D
• Controls: DEH 3000 / DEH 3000R
