SIG80-110D BreezSignature Adjustable Dual Speed Bath Fan (80/110 CFM)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
MANUALS (3)
Product Highlights
Description
SIG80-110D BreezSignature Adjustable Dual Speed Bath Fan (80/110 CFM)
The exceptional reliability of Delta's Brushless DC Motor is combined with control options including adjustable continuous low speed down to 30 CFM. Delta Breez model SIG80-110D has been awarded ENERGY STAR qualified with Brushless DC Motor engineered to run continuously for a minimum 70,000 hours; airflow rating of 110 CFM and quiet operation at less than 0.3 Sones at 0.1" static pressure as certified by the Home Ventilating Institute (HVI); power consumption of 8.2 Watts with efficiency rating of 15.3 CFM/Watt at 0.1" static pressure; fan will feature motor lock protection and self-compensating motor speed for intended airflow when static pressure is encountered. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.
Product Features
- ENERGY STAR qualified with innovative brushless DC motor technology
- Perfectly quiet operation at less than 0.3 Sones
- Full speed adjustable, 80 CFM or 110 CFM
- Allows fan to operate in full speed mode or continuous low speed mode by manual switch
- For continuous low speed mode, the fan runs continuously at a user-preset lower level (0, 30, 50, 60, or 80 CFM)
- Delay time preset positions (0.5, 5, 15, 30, 45, or 60 min)
- Includes 6" to 4" duct reducer
- Energy efficiency at 15.4 CFM/Watt
- Green and amber LED indicator lights show continuous low speed and full speed modes
Specs
| Product Type: | Ventilation Fan |
|---|---|
| Application: | Bathroom |
| Sone: | 0.8 |
| Air Flow Capacity (CFM): | 110 80 |
| Duct Size: | 6" |
| Wattage: | 14.1 |
| Speeds: | 2 |
| Amperage: | 0.38 |
| Voltage: | 120v |
| Hertz: | 60 |
| Energy Star Rated: | Yes |
| Warranty: | 3 Year |
