Ashlyn Monitor 14 Series Tub and Shower Trim (Stainless), T14464-SS
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
' fill='%23F15C02' d='M49 0C21.938 0 0 21.938 0 49s21.938 49 49 49 49-21.938 49-49S76.062 0 49 0m0 82.709a7.54 7.54 0 1 1 0-15.08 7.54 7.54 0 0 1 0 15.08m7.54-28.412a7.541 7.541 0 0 1-15.08 0V22.831a7.54 7.54 0 0 1 15.08 0v31.466z'/%3E%3C/svg%3E)
T14464-SS has been discontinued
Discontinued May 27, 2026
This product was discontinued by the manufacturer.
MANUALS (2)
Product Highlights
–
1.75 MAX GPM
Stainless Steel
Description
–
Ashlyn Monitor 14 Series Tub and Shower Trim (Stainless)
Features:
Standard Specifications:
Features:
- Backed by Delta Faucet's Lifetime Limited Warranty
- Featuring Delta H2Okinetic Technology for 3X the coverage
- Valve is not included, must purchase separately
- WaterSense certification promotes water conservation
- Monitor pressure balance valve keeps water temperature within a safe +/-3degrees F (+/-1.6degrees C), helping to protect you from sudden changes in hot or cold water pressure
- Soft, rubber spray holes allow you to easily wipe away calcium and lime build-up from the spray face of your showerhead and handshower with the touch of a finger
- Trim kit only, must order MultiChoice Universal rough-in separately to complete the unit
- Single function operation
- Single lever handle for ease of temperature control
- Meets standards set by Americans with Disabilities Act (ADA)
- Spray settings include: Full Body
- Touch Clean
- Brilliance Finish
Standard Specifications:
- 1.75 gpm @ 80 psi, 6.6 L/min @ 550 kPa
- Spout Length: 7-15/16"
- Valve Type: Single-function pressure balance cartridge
- Spray Settings: Full Body Spray
- Maintains a balanced pressure of hot and cold water even when a valve is turned on or off elsewhere in the system
- For use with MultiChoice Universal rough valve body (R10000 Series)
- Back-to-back installation capability
- Solid brass forged body
- Temperature only controlled with handle
- Field adjustable to limit handle rotation into hot water zone
- 120° maximum handle rotation
- All parts replaceable from the front of the valve
- Tub port maximum flow rate 6.0 gpm @ 60 psi with R10000-UNBX
- Shower arm overall horizontal length = 5 1/2" (138 mm), including threaded ends
- Red/blue pad print temperature indicators on handle
- Stem extension kit RP77991 can be ordered to allow for an additional 1 3/4" wall thickness, RP77991 ships with chrome escutcheon screws, and for special finishes also order RP12630 escutcheon screws in desired finish
- Parts and Finish - Lifetime limited warranty; or for commercial purchasers, 10 years for multi-family residential (apartments and condominiums) and 5 years for all other commercial uses, in each case from the date of purchase.
- Electronic Parts and Batteries (if applicable) - 5 years from the date of purchase; or for commercial purchasers, 1 year from the date of purchase. No warranty is provided on batteries.
Specs
–
| Flow Rate: | 1.75 GPM |
|---|---|
| Max Flow (GPM): | 1.75 |
| Series: | Ashlyn |
| Type: | Trim Kit |
| Finish: | Stainless Steel |
| Flow Rate (GPM): | 1.75 |
| ADA: | Yes |
