T4031C1012 has been discontinued
Discontinued January 28, 2025
This product was discontinued by the manufacturer.
MANUALS (1)
Suggested Alternative:
Ambistat Temperature Controller, High Limit, 30 F to 270 F
VIEW ALTERNATIVEProduct Highlights
–
240v, 120v
180°F Max Temp
40°F Min Temp
5°F
5-5/8"
2-1/8" Depth
Description
–
Ambient temperature compensated, high-limit controllers for agriculture and industrial applications.
Product Features:
Product Specifications:
Product Features:
- Suitable for line-voltage, low voltage, or millivolt (Powerpile) control of bulk milk tanks, beverage dispensing machines, ice cube machines, dishwashers, crop drying, tobacco curing, and similar applications.
- Enclosed snap action switches available with SPST or SPDT action.
- Models available that make or break on temperature rise.
- Screwdriver adjustment for temperature setting; external knob option.
- Immersion well not included.
Product Specifications:
- Description: Temperature Controller, High Limit, 40 F to 180 F
- Type : Remote bulb
- Application: Line-voltage, low-voltage or millivolt (Powerpile) control of bulk milk tanks, beverage dispensing machines, ice cube machines, dishwashers, crop drying, tobacco curing and similar applications.
- Output Type: Relay
- Output: 1 SPST, break on temperature rise
- Voltage: 120 Vac or 240 Vac
- Frequency: 60 Hz
- Frequency: 50 Hz
- Contact ratings (120Vac): 8.0 AFL, 48.0 ALR
- Contact ratings (240Vac): 5.1 AFL, 30.6 ALR
- Number of Sensor Inputs: 1
- Capillary Length (ft):5.5 Ft.
- Bulb Size (in.): 2-7/8 in. long x 3/8 in. diameter
- Setpoint Temperature Range: 40 F to 180 F
- Sensor Element: Copper
- Maximum Operating Temperature (F): 205F
- Differential Temperature (F): 5
- Dimensions (in.): 5-5/8 in. high x 2 in. wide x 2-1/8 in. deep
- Bulb Size (in): 2-7/8 in. long x 3/8 in. diameter
- Comments: Break on temperature rise
Specs
–
| Application: | Remote Bulb Temperature |
|---|---|
| Output: | Break on Temperature Rise 1 SPST Relay |
| Voltage: | 240v 120v |
| Hertz: | 50 60 |
| Contact Ratings 120v: | 8.0 AFL 48.0 ALR |
| Contact Ratings 240v: | 30.6 ALR 5.1 AFL |
| Height: | 5-5/8" |
| Width: | 2" |
| Depth (Inches): | 2-1/8" |
| Sensor Type: | Copper Bulb |
| Sensor Inputs: | 1 |
| Capillary Length: | 5-1/2 ft. |
| Bulb Size: | 2-7/8" x 3/8" |
| Max Temp (F): | 180°F |
| Min Temp (F): | 40°F |
| Temperature Range (F): | 40°F to 180°F |
| Differential: | 5°F |
| Max Operating Temp: | 205°F |
