5" Two-way Flanged Globe Valve, Water or Glycol (250 Cv)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$11,454.85 each
In Stock
Get 2 Fri, Jun 26 - Tue, Jun 30
MANUALS (2)
Lift Gate
–
This product weighs 148 lbs. and may require the use of a lift gate. If you do require a lift gate at your delivery, you'll have the option to add this FREE of charge when you checkout.
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
5"
250 Cv
Flanged x Flanged Connection
@240°F (Water) 150, 15 (Steam) MAX PSI
2-Way
Description
–
Used for proportional control of hot or chilled water and glycol solutions (to 50 percent concentration) and for two-position control of low pressure steam.
Features
Specifications
Features
- Sizes range from 2-1/2 to 6 inches.
- Stainless steel stem with serviceable Teflon packing.
- Valves utilize direct mounting valve actuators, Q5020/Q5022 linkages with Direct Coupled Actuators, or Pneumatic Valve Actuators to operate the valve.
- Equal Percentage flow characteristic.
Specifications
- Valve Type: Globe Valve
- Body Pattern: Two-way
- Flow Characteristic: Equal Percentage
- Controlled Medium: Chilled or hot water with up to 50% Glycol, Low pressure steam
- Connection Type: Flanged
- Max. Safe Operating Pressure: 150 psi at 240 F water or 15 psi steam
- ANSI/ASME Rating: 125
- Maximum Differential for Quiet Water Service (psi): 25 psid
- Static Pressure Rating: ANSI 125
- Ambient Temperature Rating: 40 F to 250 F
- Materials (Body): Cast Iron
- Materials (Seat): Bronze
- Materials (stem) Stainless Steel
- Used with: Q5001/Modutrol IV Motor; MP953; ML6420,21A,25; ML7420/ML7421A/ML7425; ML6984/ML7984
Specs
–
| Size: | 5" |
|---|---|
| Body Pattern: | 2-Way |
| Flow Capacity (Cv): | 250 |
| Max Pressure (PSI): | @240°F (Water) 150 15 (Steam) |
| Flow type: | Equal Percentage |
| Valve Action: | Stem up to close |
| Connection Type: | Flanged x Flanged |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
Product Q&A
1 Question1 Question
Q: What is the air actuator that goes with this valve?
Asked by Justin 2 years ago
Add your answer
Verified Reply- SupplyHouse StaffHi Justin, thanks for writing in. There are a few options, but a commonly used actuator with this valve is SKU: MP953C1489 - https://www.supplyhouse.com/Honeywell-MP953C1489-13-Pneumatic-Valve-Actuator-4-to-11-psi
