Product Highlights
–
1"
5.5 Cv
Threaded Connection
3-Way
Description
–
Three-way Cartridge Globe Valves control hot and/or chilled water for VAV terminal units, fan coil units, small reheaters and recoolers in electric/electronic temperature control systems.
Product Features
Product Specifications
Product Features
- Long stroke allows wider range of control.
- Soft valve seat provides low leakage rate.
- Inserts for 1/2 in. and 3/4 in. valves are changeable without draining valve when used with an insert replacement tool.
- Brass body and Stainless Steel stem.
- Threaded plastic cover/manual handle allows manual operation.
- Easily installed in areas where space is limited.
Product Specifications
- Valve Type: Cartridge Globe Valve
- Body Pattern: Three-way
- Flow Characteristic: Equal Percentage
- Controlled Medium: Chilled or hot water with up to 50% Glycol. Not for use with steam or fuels
- Connection Type: NPT (Female)
- Max. Safe Operating Pressure: 235 psi
- Maximum Differential Pressure Ratings (Close-off) (psi): 232 psi
- Actuation: Must be purchased separately
- Stem Travel: 1/4 in.
- Ambient Temperature: 36 to 230 F
- Leakage Rating: ANSI Class III (less than 0.02% of Cv)
Specs
–
| Size: | 1" |
|---|---|
| Flow Capacity (Cv): | 5.5 |
| Connection Type: | Threaded |
| Body Pattern: | 3-Way |
| Temperature Range: | 36° to 230°F |
