4" Three-way Flanged Diverting Valve w/ linear flow
Hover image to zoom

4" Three-way Flanged Diverting Valve w/ linear flow

Brand:
Honeywell
SKU:
VGF31LD40
Rating:
(0)
Q&A:
(1)
4" Three-way Flanged Diverting Valve w/ linear flow
Hover image to zoom
$2,497.46 each
Backorder
Backorder
Get it Wed, Apr 3 - Fri, May 3

Lift Gate

This product weighs 100.5 lbs. and may require the use of a lift gate. If you do require a lift gate at your delivery, you'll have the option to add this FREE of charge when you checkout.
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days

Product Highlights

Size icon
4"
Flow Capacity (Cv) icon
160 Cv
Connection Type icon
Flanged x Flanged Connection
Body Pattern icon
3-Way
Max Pressure (PSI) icon
175 PSI
Temperature Range (F) icon
20°F to 250°F

Description

VGF Flanged Globe Valves are used for 2-position or modulating control of hot water or chilled water-glycol solutions up to 50% concentration in heating, ventilation and air conditioning (HVAC) systems. They can be operated by ML6984/7984, ML6420/6425, ML6421/7421 Electric Linear Actuators, MP953 Pneumatic Actuators, Modutrol Motors with Q5001 valve linkage, or MN/MS Series Direct Coupled Actuators with Q5020 or Q5022 valve linkages. Three-way bodies are available in mixing or diverting style with equal percentage and linear flow characteristics, respectively. For boiler/chiller bypass applications requiring tight close-off, use VGF31/32LD diverting valves. For outdoor temperature compensation of building supply water, or modulating control of heat exchangers, use VGF31/32EM mixing valves.

Features
  • ANSI Class 125 and Class 250 cast iron bodies with flanged end connections.
  • Face-to-face flange dimensions per ANSI/ISA S75.03 standard.
  • Sizes from 2-1/2 to 6 inches.
  • Stainless steel trim standard for long life span.
  • Self-adjusting packing.
  • Accurate positioning with equal percentage and linear flow characteristics to ensure precise temperature control.
  • Universal bonnet for direct-coupled electric and pneumatic actuators for easy mounting, or linkage coupled Modutrol Motors and MN/MS Series direct coupled actuators.
  • Constant total flow throughout full plug travel (3-way diverting models).
  • Not suitable for combustible gasses.

Specs

Size:

4"

Flow Capacity (Cv):

160

Connection Type:

Flanged x Flanged

Flow type:

Linear

Body Pattern:

3-Way

Max Pressure (PSI):

175

ANSI/ASME Rating:

125

Temperature Range (F):

20°F to 250°F

Max Temp (F):

250°F

Min Temp (F):

20°F

Stem Travel:

1-1/2"

Valve Type:

Globe

Controlled Fluid:

Chilled or hot water with up to 50% Glycol

Valve Action:

Diverting

Stem Down to Close AB-A

Differential (PSI):

34

Leakage Rating:

Port B seat leakage 0.1%

Port A seat leakage: 0.5%

Bonnet Size:

1-7/8"

Material:

Cast Iron ASTM A126 Class B
