Pneumatic Temperature Indicator (40°F to 65°F)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
' fill='%23F15C02' d='M49 0C21.938 0 0 21.938 0 49s21.938 49 49 49 49-21.938 49-49S76.062 0 49 0m0 82.709a7.54 7.54 0 1 1 0-15.08 7.54 7.54 0 0 1 0 15.08m7.54-28.412a7.541 7.541 0 0 1-15.08 0V22.831a7.54 7.54 0 0 1 15.08 0v31.466z'/%3E%3C/svg%3E)
T-5500-1058 has been discontinued
Discontinued January 17, 2024
This product was discontinued by the manufacturer.
MANUALS (1)
Product Highlights
–
65°F Max Temp
40°F Min Temp
40°F to 65°F
1/8" NPT Connection
Flush, Surface, Back
Description
–
Note: Image may not be actual representation of item.
The T-5500 Series Pneumatic Temperature
Indicator provides continuous indication of the
temperature measurement of a transmitter in a
3 to 15 psig (21 to 105 kPa) pneumatic
transmission system.
Features:
Features:
- available in two models T-5500: 3-1/2 in. dial size, ± 1/2% accuracy & T-5502: 2-1/2 in. dial size, ± 3-2-3% accuracy
- equivalent Fahrenheit and metric scale printed on dial face. The dial range must match the range of the transmitter which is being used.
- easy readability
- removable clear plastic lens cover for cleaning and recalibration
- equipped to be flush or surface mounted
- notched U-clamps for flush-mounting break off to accommodate panel thicknesses of 1/16 to 3/4 in. (2 to 19 mm)
Specs
–
| Application: | Heating |
|---|---|
| Max Temp (F): | 65°F |
| Min Temp (F): | 40°F |
| Temperature Range (F): | 40°F to 65°F |
| Temperature Range: | -17.8° to 37.8°C |
| Dial Size: | 3-1/2" |
| Measures: | Celsius Fahrenheit |
| Connection Type: | 1/8" NPT |
| Accuracy: | +/- 1/2% |
| Mount: | Flush Surface Back |
| Ambient Temperature: | -20°F to +150°F |
| Type: | Dry |
| PSI Range: | 3-15 |
