$168.54 each
Out of Stock
MANUALS (1)
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
30 Amps
Description
–
Features
Specifications
- Leviton's Power Interrupting line of industrial and hospital grade plugs, connectors and flush receptacles provide a reliable solution while increasing safety and reducing the likelihood of equipment damage.
Specifications
- Flammability: Rated V-0 per UL 94
- RoHS Compliant: TRUE
- Body Material: Nylon
- Cord-Clamp: Nylon
- Line Contacts: Brass
- Assembly Screws: Steel, Zinc Plated
- Grounding: Grounding
- Feature: Power Interrupting
- Amperage: 30/20 A
- cULus: Listed
- Terminal Screws: Brass 8-32
- Environment: Dry
- Grounding Screw: Brass 8-32
- Voltage: 250 VDC/600 VAC
- Operating Temperature: -40 °C to 105 °C
- Torque Range: 14-16 in-lbs
- Pole: 3
- Blades/Contacts: Solid Brass
- UL: 498
- Wire: 4
- Terminal Accom.: 12-4 AWG
- Dielectric Voltage: Withstands 2000V per UL498
- Product ID: Ratings are permanently marked on device
- Country of Origin: Mexico
- Current Interrupting: Certified for current interrupting at full rated current
- Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current
- Interior Material: Phenolic
Specs
–
| Ground: | Grounding |
|---|---|
| Poles: | 3 |
| Country of Origin: | Mexico |
| Amperage: | 30 |
