Main product image of 20A, 277V Flush Mount Locking Receptacle, Industrial Grade
Magnifying glass
Hover image to zoom

20A, 277V Flush Mount Locking Receptacle, Industrial Grade

Brand:
Leviton
SKU:
2330-IG
Rating:
(0)
Q&A:
(0)
20A, 277V Flush Mount Locking Receptacle, Industrial Grade
Magnifying glass
Hover image to zoom
$19.53 each
Out of Stock
Out of Stock
Get it Tue, Jul 21 - Tue, Jul 28
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days

Product Highlights

–
Product Highlight: Material
Valox 357
Product Highlight: Amperage
20 Amps
Product Highlight: Color
Orange
Product Highlight: Warranty
Lifetime Limited Warranty

Description

–
Features
  • Leviton's Industrial Grade Locking Devices are built to provide unparalleled quality and superior performance in the most severe industrial settings. Leviton combines the best materials available with superior production standards to produce a broad selection of Locking Devices of unmatched flexibility and dependability.
  • L7-20R

Specifications
  • Amperage: 20 A
  • Terminal Accom.: 14-8 AWG
  • Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
  • Voltage: 277 VAC
  • Strap Material: Nickel-Plated Brass
  • Dielectric Voltage: Withstands 2000V per UL498
  • NOM: 57
  • Line Contacts: Brass
  • UL: 498
  • Operating Temperature: -40 °C to 60 °C
  • Feature: Isolated Ground
  • Screw Terminal Torque: 14-18 in-lbs
  • Cover Material: Valox 357
  • Ground Clips: Nickel-Plated Brass
  • Termination: Back & Side
  • Country of Origin: Mexico
  • Current Limiting: Full Rated Current
  • Flammability: Rated V-0 per UL 94
  • Grounding Screw: Chromated Brass
  • CSA: C22.2 No. 42
  • Grounding: Isolated Ground
  • Terminal ID: Marked on Device
  • Horsepower Rating: 2 HP
  • Product ID: Ratings and NEMA I.D. permanently marked on device
  • ANSI: C-73
  • Terminal Clamps: Zinc-Plated Brass
  • Body Material: Valox 357
  • Wire: 3
  • Face Material: Valox
  • Terminal Screws: Chromated Brass
  • Pole: 2
  • Color: Orange
  • Environment: Corrosive
  • Warranty: Limited Lifetime Warranty
  • NEMA: WD-1 & WD-6
  • UL Fed Spec: W-C-596
  • Brand: V-0-Max
  • Ground Contacts: Brass
  • Base Material: Valox
  • RoHS Compliant: TRUE

Specs

–
Terminations:

Side Wire

Back Wire

NEMA Rating:

WD-1

Material:

Valox 357

Poles:

2

Country of Origin:

Mexico

Amperage:

20

Color:

Orange

Ground:

Isolated Ground

Warranty:

Lifetime Limited

Series:

V-0-Max
