Description
–
Features
- Termination: Back
- Voltage: 600 VAC
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- Body Material: Nylon
- Strap Material: Thermoplastic Nylon
- CSA C22.2 No. 42: File LR-406
- RoHS Compliant: TRUE
- Color: White
- Screw Terminal Torque: 10-14 in-lbs
- Wire: 3
- Terminal Accom.: 18-10 AWG
- Grounding Screw: Brass 8-32
- Product ID: Ratings and NEMA I.D. permanently marked on device
- Line Contacts: Solid Brass
- Country of Origin: Mexico
- At Rated Voltage: 3 HP
- Grounding: Grounding
- ANSI: C-73
- Operating Temperature: -40 °C to 60 °C
- Dielectric Voltage: Withstands 2000V per UL498
- UL Fed Spec WC-596: File E13393
- Amperage: 20 A
- Pole: 2
- Current Limiting: Full Rated Current
- NOM: 57
- Terminal Screws: Brass 10-32
- Face Material: Nylon
- UL498: File E13393
- NEMA: WD-6
- Warranty: Limited Lifetime Warranty
- Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
- Flammability: Rated V-2 per UL 94
Specs
–
| Country of Origin: | Mexico |
|---|
