$18.04 each
Out of Stock
Get it Tue, Jul 21 - Tue, Jul 28
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
Nylon
20 Amps
White, Black
Lifetime Limited Warranty
Description
–
Features
Specifications
- Deep slotted triple drive face module and cord clamp screws
- Backed-out, color-coded brass terminal screws
- Thick-walled, super tough nylon housing resists abuse and impact
- L14-20P
- Single piece external cord clamp includes catalogue number and NEMA configuration for easy identification
- One piece contacts reduce friction and overheating
- Rugged nylon construction resists impact, sunlight, chemicals, and rough use
- Leviton's Black & White line of industrial grade plugs, connectors, flanged inlets, and outlets offer superior performance, long lasting reliability and features that are backed by a limited lifetime warranty:
- Plugs ship with standard white and black cord clamp. Color-coded cord clamps available to identify amperage or equipment. Choose from blue, green, yellow, red, and orange.
- Nylon face module features Amperage, Voltage, and NEMA configuration molded into face for easy identification and replacement.
- Deep wire wells with transparent wiring chambers
- External cord clamp accepts wire mesh connection grips
- Industry exclusive limited lifetime warranty
- Fluted nylon housing makes it easier to grip with gloves and in debris-laden environments
- For fast assembly, Black & White devices feature:
- Unique cord clamp accepts wide range of cord sizes
Specifications
- Assembly Screws: Steel, Zinc Plated
- Cord Range: 0.560 to 0.775
- Country of Origin: Mexico
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- Torque Range: 10-14 in-lbs
- Amperage: 20 A
- Environment: Dry
- Cord-Clamp: Nylon
- Wire Gauge: 14-10 AWG
- NEMA: WD-6
- CSA C22.2 No. 42: File LR-406
- RoHS Compliant: TRUE
- Product ID: Ratings are permanently marked on device
- Warranty: Limited Lifetime Warranty
- Terminal Accom.: 18-10 AWG
- Operating Temperature: -40 °C to 60 °C
- Color: Black-White
- At Rated Voltage: 2 HP L-L/1 HP L-N
- Voltage: 125/250 VAC
- UL Fed Spec WC-596: File E13393
- Body Material: Impact Modified Nylon
- Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
- Wire Module: Nylon
- Dielectric Voltage: Withstands 2000V per UL498
- Back Cover: Thermoplastic
- Device Type: Locking Plug
- Grounding: Grounding
- NOM: 57
- Clamp Insert: Nylon
- Current Interrupting: Certified for current interrupting at full rated current
- Wire: 4
- Blades/Contacts: Solid Brass
- ANSI: C-73
- Terminal Screws: Brass
- UL498: File E13393
- Brand: Black and White
- Pole: 3
- Flammability: Rated HB or better UL94
Specs
–
| Material: | Nylon |
|---|---|
| NEMA Rating: | WD-6 |
| Product Type: | Locking Plug |
| Series: | Black & White |
| Ground: | Grounding |
| Poles: | 3 |
| Amperage: | 20 |
| Color: | White Black |
| Warranty: | Lifetime Limited |
| Country of Origin: | Mexico |
