Product Highlights
–
30 Amps
Black
Nylon
Lifetime Limited Warranty
Description
–
Features
Specifications
- Rugged nylon construction resists impact, sunlight, chemicals, and rough use
- Industry exclusive limited lifetime warranty
- One piece contacts reduce friction and overheating
- Leviton's Black & White line of industrial grade plugs, connectors, flanged inlets, and outlets offer superior performance, long lasting reliability and features that are backed by a limited lifetime warranty:
- L15-30R
- Unique cord clamp accepts wide range of cord sizes
Specifications
- Warranty: Limited Lifetime Warranty Warranty
- Terminal Accom.: 18-10 AWG
- Wire: 4
- Wire Gauge: 14-8 AWG
- Cord Range: .595 - 1.150
- NEMA: WD-6
- Clamp Insert: Nylon
- Terminal Screws: Brass
- NOM: 57
- Wire Module: Nylon
- Cord-Clamp: Nylon
- Blades/Contacts: Solid Brass
- Product ID: Ratings are permanently marked on device
- RoHS Compliant: TRUE
- At Rated Voltage: 3 HP
- Color: Black
- Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
- CSA C22.2 No. 42: File LR-406
- ANSI: C-73
- Device Type: Locking Connector
- Operating Temperature: -40 °C to 60 °C
- Brand: Black and White
- Back Cover: Thermoplastic
- Current Interrupting: Certified for current interrupting at full rated current
- Grounding: Grounding
- Flammability: Rated HB or better UL94
- Dielectric Voltage: Withstands 2000V per UL498
- Environment: Dry
- Amperage: 30 A
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- UL498: File E13393
- Country of Origin: Mexico
- Pole: 3
- Voltage: 250 VAC
- Assembly Screws: Steel, Zinc Plated
- UL Fed Spec WC-596: File E13393
- Body Material: Impact Modified Nylon
- Phase: 3-Phase
Specs
–
| Product Type: | Locking Connector |
|---|---|
| Amperage: | 30 |
| Color: | Black |
| Material: | Nylon |
| Ground: | Grounding |
| NEMA Rating: | WD-6 |
| Warranty: | Lifetime Limited |
| Poles: | 3 |
| Series: | Black & White |
| Country of Origin: | Mexico |
