$69.42 each
In Stock
Get 18 Tue, Jul 7
Order by today, receive Tuesday
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
50 Amps
White, Black
Lifetime Limited Warranty
Description
–
Features
Specifications
- Non-NEMA
- Industry exclusive limited lifetime warranty
- Rugged nylon construction resists impact, sunlight, chemicals, and rough use
- Unique cord clamp accepts wide range of cord sizes
- One piece contacts reduce friction and overheating
Specifications
- Wire: 4
- Assembly Screws: Brass
- NEMA: Non-NEMA
- UL 498: File E13399
- Pole: 3
- Warranty: Limited Lifetime Warranty
- Cord Range: .680 - 1.125
- Temperature Rise: Max 30 ºC temp rise at full-rated current after 150 cycles of OL at 150% rated DC current
- NOM: 57
- Ground Post: Brass
- Dielectric Voltage Withstand: 2000V minimum per UL 498
- Product ID: Ratings and Catalogue No. molded into face and stamped into shroud
- Brand: Black and White
- RoHS: Compliant
- Maximum Working Voltage: 250V DC/600V AC as rated
- Terminal Accom.: #10 min to #4max AWG Solid or Stranded Wire
- Color: Black-White
- Terminal Set Screw: SS 302/304
- Current Interrupting: Certified for current interrupting at full rated current
- Voltage: 250 VDC/600 VAC
- Terminal ID: X, W, Y, Z and Green for ground
- Housing Material: Nylon
- Plug Blade Shroud: SS 302/304
- Amperage: 50 A
- Face Module: Nylon
- RoHS Compliant: FALSE
- Standard Cable Clamp: Nylon
- Grounding: Grounding
- Torque Range: allen wrench to 35 inch-lbs
- Environment: Dry
- Operating Temperature: -40 °C to 75 °C
- Dust Shield: Santoprene TPE
- Wiring Chamber: Nylon
- Cable Clamp Screw: Philips Head, SS 304
- Country of Origin: Mexico
- Terminal Block: 0.062inch thick Copper
- Ground Shunt: Bronze
- CSA C22.2 No. 42: File 152105
- Flammability: UL94V-2
- Plug Blade: 0.1000inch thick Brass
Specs
–
| Ground: | Grounding |
|---|---|
| Amperage: | 50 |
| Series: | Black & White |
| NEMA Rating: | Non-NEMA |
| Country of Origin: | Mexico |
| Poles: | 3 |
| Color: | White Black |
| Warranty: | Lifetime Limited |
