$9.55 each
Out of Stock
Get it Tue, Jul 21 - Tue, Jul 28
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
Nylon
Black
Lifetime Limited Warranty
15 Amps
Description
–
Features
Specifications
- Rugged nylon construction resists impact, sunlight, chemicals, and rough use
- Industry exclusive limited lifetime warranty
- Unique cord clamp accepts wide range of cord sizes
- Leviton's Black & White line of industrial grade plugs, connectors, flanged inlets, and outlets offer superior performance, long lasting reliability and features that are backed by a limited lifetime warranty:
- One piece contacts reduce friction and overheating
- L5-15P
Specifications
- Voltage: 125 VAC
- Wire Gauge: 18-10 AWG
- Color: Black
- UL Fed Spec WC-596: File E13393
- CSA C22.2 No. 42: File LR-406
- Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
- Operating Temperature: -40 °C to 60 °C
- Feature: All Black
- Pole: 2
- Grounding: Grounding
- Terminal Accom.: 18-10 AWG
- Body Material: Impact Modified Nylon
- Cord Range: .240 - .700
- Clamp Insert: Nylon
- Current Interrupting: Certified for current interrupting at full rated current
- NEMA: WD-6
- Assembly Screws: Steel, Zinc Plated
- Blades/Contacts: Solid Brass
- Cord-Clamp: Nylon
- Back Cover: Thermoplastic
- Wire: 3
- Product ID: Ratings and NEMA I.D. permanently marked on device
- Dielectric Voltage: Withstands 2000V per UL498
- RoHS Compliant: TRUE
- Warranty: Limited Lifetime Warranty Warranty
- Country of Origin: Mexico
- Flammability: Rated HB or better UL94
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- Wire Module: Nylon
- NOM Certified: 57
- Amperage: 15 A
- Horsepower Rating: 1/2 HP
- Brand: Black and White
- ANSI: C-73
- Environment: Dry
- Terminal Screws: Brass
Specs
–
| Ground: | Grounding |
|---|---|
| Series: | Black & White |
| NEMA Rating: | WD-6 |
| Material: | Nylon |
| Color: | Black |
| Warranty: | Lifetime Limited |
| Country of Origin: | Mexico |
| Poles: | 2 |
| Amperage: | 15 |
