$39.48 each
In Stock
Get 1 Thu, Jul 9 - Fri, Jul 10
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
White, Black
10 years Warranty
Nylon
15 Amps
Description
–
Features
Specifications
- One piece contacts reduce friction and overheating
- Ratings and NEMA I.D. permanently marked on device
- L5-15R
- Rugged nylon construction resists impact, sunlight, chemicals, and rough use
- Industry exclusive limited lifetime warranty
Specifications
- Cord-Clamp: Nylon
- Current Interrupting: Certified for current interrupting at full rated current
- Wire Gauge: 18-10 AWG
- Operating Temperature: -40 °C to 60 °C
- Feature: Power Indication
- Cord Range: .240 - .700
- Country of Origin: Mexico
- UL Fed Spec WC-596: File E13393
- Terminal Screws: Brass
- Wire: 3
- Environment: Dry
- Wire Module: Nylon
- Dielectric Voltage: Withstands 2000V per UL498
- Body Material: Impact Modified Nylon
- Flammability: Rated HB or better UL94
- Terminal Accom.: 18-10 AWG
- Grounding: Grounding
- Clamp Insert: Nylon
- NOM Certified: 57
- NEMA: WD-6
- RoHS Compliant: TRUE
- CSA C22.2 No. 42: File LR-406
- Voltage: 125 VAC
- Amperage: 15 A
- Warranty: 10-Year Limited
- Assembly Screws: Steel, Zinc Plated
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- Product ID: Ratings and NEMA I.D. permanently marked on device
- Color: Black-White
- Brand: Black and White
- Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
- ANSI: C-73
- Blades/Contacts: Solid Brass
- Back Cover: Thermoplastic
- Horsepower Rating: 1/2 HP
- Pole: 2
Specs
–
| Ground: | Grounding |
|---|---|
| Color: | White Black |
| Warranty: | 10 years |
| Country of Origin: | Mexico |
| Material: | Nylon |
| NEMA Rating: | WD-6 |
| Amperage: | 15 |
| Poles: | 2 |
| Series: | Black & White |
