20A, 125V NEMA 5-20R, 2P, 3W, Connector, Straight Blade, Grounding, Python (Black)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$23.91 each
Out of Stock
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
Black
Super Tough Nylon
20 Amps
Lifetime Limited Warranty
Description
–
Features
Specifications
- When it comes to the demanding nature of today's commercial and industrial electrical environments, ruggedness and ease of installation are the features you look for first in any line of plugs and connectors. Leviton's Python straight-blade plugs and connectors hold up under the most exacting requirements, the toughest conditions, the roughest handling. Python's exceptional design features meet your needs for a quick, easy-to-wire plug and connector system, a must in today's faced-paced world where lost minutes on a job can translate into lost profits.
- 5-20R
Specifications
- Wire: 3
- NEMA: WD-6
- NOM: 57
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- Back Cover: Thermoplastic
- Cord Range: .245 - .700
- Voltage: 125 VAC
- Environment: Dry
- Device Type: Straight Blade Connector
- Assembly Screws: Steel, Zinc Plated
- Warranty: Limited Lifetime Warranty
- Current Interrupting: Certified for current interrupting at full rated current
- Blades/Contacts: Solid Brass
- Country of Origin: Mexico
- Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
- Brand: Python
- Color: Black
- Clamp Insert: Nylon
- Product ID: Ratings and NEMA I.D. permanently marked on device
- Dielectric Voltage: Withstands 2000V per UL498
- Wire Module: Nylon
- Pole: 2
- CSA C22.2 No. 42: File LR-406
- UL 498: File E13399
- Cord-Clamp: Nylon
- Terminal Accom.: 18-10 AWG
- Body Material: Super Tough Nylon
- Amperage: 20 A
- Terminal Screws: Brass
- Grounding: Grounding
- RoHS Compliant: TRUE
- Operating Temperature: -40 °C to 60 °C
- Flammability: Rated V-2 per UL 94
- ANSI: C-73
Specs
–
| Color: | Black |
|---|---|
| NEMA Rating: | WD-6 |
| Product Type: | Straight Blade Connector |
| Material: | Super Tough Nylon |
| Amperage: | 20 |
| Ground: | Grounding |
| Warranty: | Lifetime Limited |
| Series: | Python |
| Country of Origin: | Mexico |
| Poles: | 2 |
