Main product image of 20A, 120/277V Toggle Framed Double-pole AC Quiet Switch, Commercial Spec Grade, Grounding, Side Wired(Brown)
Magnifying glass
Hover image to zoom

20A, 120/277V Toggle Framed Double-pole AC Quiet Switch, Commercial Spec Grade, Grounding, Side Wired(Brown)

Brand:
Leviton
SKU:
54522-2
Rating:
(0)
Q&A:
(0)
20A, 120/277V Toggle Framed Double-pole AC Quiet Switch, Commercial Spec Grade, Grounding, Side Wired(Brown)
Magnifying glass
Hover image to zoom
$13.13 each
Out of Stock
Out of Stock
Get it Tue, Oct 20 - Tue, Oct 27
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days

Product Highlights

–
Product Highlight: Warranty
10 years Warranty
Product Highlight: Color
Brown
Product Highlight: Grade
Commercial
Product Highlight: Amperage
20 Amps
Product Highlight: Material
Thermoplastic

Description

–
Features
  • Leviton's Commercial Specification Grade switches are designed to offer outstanding reliability and top performance in commercial settings. Ideal applications include municipal facilities, government buildings, malls, department stores, hospital and health care facilities, office buildings, schools, colleges, universities, houses of worship and cultural institutions. Leviton offers a large selection of 15 and 20 Amp Commercial switches, available in a wide variety of colors, wiring options and other features.

Specifications
  • Warranty: 10-Year Limited
  • RoHS Compliant: TRUE
  • Body Material: Thermoplastic
  • Temperature Rise: Maximum 30 degrees C rise
  • Screw Terminal Torque: 14-18 in-lbs
  • CSA C22.2 No. 111: File #152105
  • Voltage: 120/277 VAC
  • Country of Origin: Please Contact Customer Service
  • Actuator Material: Thermoplastic
  • Feature 3: Framed
  • Terminal Accom.: 14-12 AWG
  • Grade: Commercial Specification Grade
  • Color: Brown
  • Warranty: 10-Year Limited
  • ANSI: C-73
  • NEMA: WD-1 & WD-6
  • Product ID: Stamped on Strap
  • UL Standard: UL 20
  • Cover Material: Nylon
  • NOM: 57
  • Max. Amperage: 16 Amp
  • Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
  • Terminal Screws: Steel 8-32
  • Amperage: 20 A
  • Base Material: PBT
  • Contacts: Silver-Cadmium .031 Thick
  • Strap Material: Steel
  • UL Fed Spec WS896E: File #E7458
  • HP Rating: 1HP-120V 2HP-240V-277V
  • Termination: Side Wire
  • Toggle: Polycarbonate
  • Operating Temperature: -40 °C to 65 °C
  • Flammability: Rated V-2 per UL 94
  • Dielectric Voltage: Withstands 1500V for 1 minute
  • Device Type: Toggle Switch
  • Function: Double-Pole

Specs

–
NEMA Rating:

WD-1

Warranty:

10 years

Color:

Brown

Product Type:

Toggle Switch

Grade:

Commercial

Terminations:

Side Wire

Amperage:

20

Material:

Thermoplastic
