20A, 250V NEMA 6-20P, 2P, 3W, Plug, Straight Blade, Grounding, Python (Yellow)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$16.37 each
Out of Stock
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
2 years Warranty
20 Amps
Yellow
Super Tough Nylon
Description
–
Features
Specifications
- 6-20P
- When it comes to the demanding nature of today's commercial and industrial electrical environments, ruggedness and ease of installation are the features you look for first in any line of plugs and connectors. Leviton's Python straight-blade plugs and connectors hold up under the most exacting requirements, the toughest conditions, the roughest handling. Python's exceptional design features meet your needs for a quick, easy-to-wire plug and connector system, a must in today's faced-paced world where lost minutes on a job can translate into lost profits.
Specifications
- Terminal Accom.: 18-10 AWG
- Operating Temperature: -40 °C to 60 °C
- Color: Yellow
- Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
- NEMA: WD-6
- Cord Range: .245 - .700
- Grounding: Grounding
- RoHS Compliant: TRUE
- Amperage: 20 A
- UL 498: File E13399
- Flammability: Rated V-2 per UL 94
- Country of Origin: Mexico
- Wire: 3
- Torque Range: 12-14 in-lbs
- Clamp Insert: Nylon
- Cord-Clamp: Nylon
- Back Cover: Thermoplastic
- Dielectric Voltage: Withstands 2000V per UL498
- Voltage: 250 VAC
- Terminal Screws: Brass
- ANSI: C-73
- Pole: 2
- Body Material: Super Tough Nylon
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- Device Type: Straight Blade Plug
- Blades/Contacts: Solid Brass
- Assembly Screws: Steel, Zinc Plated
- Product ID: Ratings and NEMA I.D. permanently marked on device
- Environment: Dry
- CSA C22.2 No. 42: File LR-406
- Wire Module: Nylon
- Brand: Python
- NOM: 57
- Current Interrupting: Certified for current interrupting at full rated current
- Warranty: 2-Year Limited
Specs
–
| NEMA Rating: | WD-6 |
|---|---|
| Warranty: | 2 years |
| Ground: | Grounding |
| Product Type: | Straight Blade Plug |
| Amperage: | 20 |
| Poles: | 2 |
| Color: | Yellow |
| Country of Origin: | Mexico |
| Material: | Super Tough Nylon |
| Series: | Python |
