$16.34 each
Out of Stock
Get it Tue, Jul 21 - Tue, Jul 28
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
White
Description
–
Features
Specifications
- Tine geometry prevents arcing damage where plug and connector make contact
- Patented Retention Force Technology (RFT) protects against tine damage and increases system longevity
- Jack with internal shutter protects against dust and debris
- Robust IDCs can withstand 20 re-termination cycles and connector contacts are tested for 750 plug-mating cycles to ensure system longevity
- ETL verified to meet the IEC 60512-99-002 standard for support of IEEE 802.3bt Type 4 PoE (90-watt) applications
- Shielding provides EMI/RFI protection, signal isolation, and excellent alien crosstalk (AXT) suppression
- Select jacks supplied with interchangeable icons (voice, data, A/V, and blank, color coded to match the jack face) for easy identification and tracking of data, voice, or other functions
- Unique design supports tool-free termination/re-termination and requires no specialized termination tool
- Available in 13 ANSI/TIA-606-C compatible colors for color coding
- Independently tested and guaranteed to exceed all component, permanent link, and channel margins
- Short jack design supports a wider range of applications (e.g. shallow boxes, enclosures, bend radius, etc.)
- Solid metal body dissipates 53% more heat than traditional plastic, minimizing damage from excess heat in PoE applications
- For Power over Ethernet, RFT maintains contact force between plug and connector, preventing arcing from intermittent disconnects
- Terminates from 26 to 22 AWG solid or stranded conductors for use on various cable types
- Will exceed IEEE 802.3bt standard up to 0.5 amps per conductor (100 watts) continuously
Specifications
- Country of Origin: United States
- Shielding: Shielded
- RoHS Compliant: TRUE
- Brand: Atlas-X1
- Color: White
- Category Rating: Cat 5e
Specs
–
| Series: | Atlas-X1 |
|---|---|
| Color: | White |
