Low Temp. Refrigeration Control w/ 72" Capillary (-55 to 0 F)

Name: Low Temp. Refrigeration Control w/ 72" Capillary (-55 to 0 F)
Brand: Ranco
SKU: O10-1000
Price: 140.17 USD
Availability: OutOfStock

Brand:

Ranco

SKU:

O10-1000

Rating:

(0)

Q&A:

(0)

Low Temp. Refrigeration Control w/ 72" Capillary (-55 to 0 F)

Hover image to zoom

We no longer carry O10-1000

Unavailable since December 4, 2025

MANUALS (2)

Product Highlights

–

3° to 20°F

SPST

-55°F Min Temp

400 MAX PSI

100 PSI

0°F Max Temp

Description

–

Recognizing the need for flexibility in design of refrigeration equipment, these controls offer a wide selection for such products as self-contained refrigerators, freezers, coolers, walk-in units, and refrigeration display cases.

Features

Maximum adjustment accuracy with 7 revolution range adjustment screws
NEMA 1 enclosure with non-conductive cover
Front-located captive cover screw
Large easy-to-read scale plate
Universal mounting and compact design
Laser-welded bellows for extended life

Specs

–

Differential:	3° to 20°F
Switch Action:	SPST
Capillary Length:	72"
Min Temp (F):	-55°F
Max Pressure (PSI):	400
Min Pressure (PSI):	100
Max Temp (F):	0°F
