1C Programmable Thermostat

Overview:
The Robertshaw Climate™ RS1010 COOL ONLY thermostat is an impressive new low cost thermostat. With a beautiful vibrant blue backlight, the RS1000 series is Simply The Right Choice™ for an economical programmable cool only thermostat for new and replacement residential applications. The thermostat can be configured for Fahrenheit or Celsius, and can be used as manual or 5-1-1 day programmable operation.

Features:

• Cooling Only
• Selectable Fahrenheit or Celsius Display
• 5-1-1 Day Programmable & Manual (non-programmable) Operation
• 4 Events / Day
• Temporary Override with Override Icon on Display
• Adjustable Temperature Differential
• Compressor Short Cycle Protection – Reduces wear and tear of HVAC equipment compressor
• Worry Free Memory Retention – Maintains programmed parameters even during power outages
• HVAC equipment control using dry contact relays
• Quick Wire Terminal Block – Uses sturdy wire clamps

Specifications:

• Thermostat Family: RS1000 Series
• Type: Electronic
• HVAC Equipment: Electric
• Control: Cool, Off
• Humidity: No
• Programmability: Non-Programmable 5-1-1 Day
• Events/Day: 4
• Voltage Type: Low
• Voltage: 24V, Battery Required
• Battery: Yes
• Remote Sensors: No
• Color: White
• Orientation:
• Horizontal
• Product Weight : 10 oz.
• Electrical Contact Rating : 24V AC (18-30V AC) 1 amp maximum load per terminal
• Temp. Control Range : 40°F to 90°F (5°C to 32°C)
• Accuracy : ± 1°F (± 0.5°C)
• Power : 2 AAA alkaline batteries included
• System Configurations : Cooling Only
• Terminations : R, G, Y
