Programmable Receiver, Monostable, 4 PNP, 2 Push Buttons, 6 Indicating LEDs, 200mA (24 VDC)
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$101.27 each
Out of Stock
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
24 VDC
18 Months Warranty
Description
–
- Product Or Component Type: wireless receiver
- Vibration Resistance: +/- 7.5 mm 5-14 Hz)IEC 60068-2-6 || 2 gn 8-150 Hz)IEC 60068-2-6
- Maximum Sensing Distance: 100 m in free field || 25 m transmitter in a plastic box type XAL D and receiver in a metal enclosure || 40 m transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna
- Output Contacts: 4 PNP
- Utilisation Category: DC-13 EN/IEC 60947-5-1
- Standards: EN/IEC 60947-5-1
- Depth: 75 mm
- Mounting Support: 35 mm symmetrical DIN rail conforming to EN/IEC 60715 || mounting plate
- Max Power Consumption In W: 1 mW
- [Us] Rated Supply Voltage: 24 V DC - 15...20 %
- Operating Position: any position without derating
- Electrical Connection: 1 conductor cable 0.14-2.5 mm squared - AWG 26...AWG 14 - solid - without cable end IEC 60947-1 || 2 conductors cable 0.14-1.5 mm squared - AWG 26...AWG 16 - solid - without cable end IEC 60947-1 || 1 conductor cable 0.14-4 mm squared - AWG 26...AWG 12 - flexible - with cable end IEC 60947-1 || 2 conductors cable 0.14-1.5 mm squared - AWG 26...AWG 16 - flexible - with cable end IEC 60947-1
- Function Of Module: bi-stable
- Insulation Resistance: > 500 MOhm 500 V DC NF C 20-030
- [Ui] Rated Insulation Voltage: 60 V IEC 60664-1
- Product Specific Application: interface to Harmony hub
- Rohs Exemption Information: Yes
- Pollution Degree: 2 IEC 60664-1
- Warranty: 18 months
- Bandwidth: 5-5 MHz
- Antenna Type: omnidirectional
- Shock Resistance: 10 gn 16 ms) 6000 shocks IEC 60068-2-27
- Eu Rohs Directive: Pro-active compliance (Product out of EU RoHS legal scope)
- Transmission Frequency: 2405 MHz
- Sustainable Offer Status: Green Premium product
- Reach Regulation: Reference contains Substances of Very High Concern above the threshold
- Housing Material: self-extinguishing plastic
- Tightening Torque: 0.5-1 N.m EN/IEC 60947-1
- Relative Humidity: 90-90 % -20-55 °C, without condensation ETSI EN 300 440-1
- Output Type: transistor PNP
- Rated Short-Duration Power Frequency Withstand Voltage: 1 kV 50 Hz EN/IEC 60947-5-1
- Breaking Capacity: 4.8 W per output)
- Channels Utilisation: 1 Harmony Hub per receiver
- California Proposition 65: WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Status Led: 1 LED Green power ON || 1 LED green and yellow reception signal || 4 LEDs Green relay ON
- Maximum Switching Current: 0.2 mA DC
- Device Short Name: ZBRRH
- Device Short Name: ZBRRH
- Maximum Power Consumption In W: 20 W DC
- Short-Circuit Protection: 0.4 A fuse fast blow
- Radio Agreement: RSS || SRRC || ANATEL || ARIB T66 || FCC || ICASA
- [Uimp] Rated Impulse Withstand Voltage: 0.8 kV
- Overvoltage Category: III IEC 60664-1
- Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Net Weight: 0.13 kg
- Number Of Channels: 1
- Maximum Voltage Drop: <2 V DC 2 A
- Height: 108 mm
- Time Delay Range: 0.5 s - 15...15 %)
- Electromagnetic Compatibility: immunity for industrial environments conforming to EN/IEC 61000-6-2 || conducted and radiated emissions class B conforming to CISPR 22 || electrostatic discharge immunity test - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 || electrostatic discharge immunity test - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 || susceptibility to electromagnetic fields - test level: 10 V/m (80...2000 MHz) conforming to IEC 61000-4-3 || susceptibility to electromagnetic fields - test level: 3 V/m (80...2700 MHz, distance = 20 m) conforming to IEC 61000-4-3 || electrical fast transient/burst immunity test - test level: 2 kV (power supply wires) conforming to IEC 61000-4-4 || conducted RF disturbances - test level: 10 V conforming to IEC 61000-4-6 || radiated emission conforming to ETSI EN 300 440-1 || conducted emission conforming to EN 300-489-1 || conducted emission conforming to ETSI EN 300 489-3 || radiated emission conforming to ETSI EN 300 440-2 || electrical fast transient/burst immunity test - test level: 1 kV (PNP output wires) conforming to IEC 61000-4-4 || 1.2/50 µs shock waves immunity test - test level: 0.5 kV (differential mode) conforming to IEC 61000-4-5 || 1.2/50 µs shock waves immunity test - test level: 1 kV (common mode) conforming to IEC 61000-4-5 || immunity to microbreaks and voltage drops - test level: 7 ms conforming to IEC 61000-4-11
- Ip Degree Of Protection: IP20 IEC 60529 casing) || IP20 terminals)
Specs
–
| Voltage: | 24 VDC |
|---|---|
| Warranty: | 18 Months |
