100A Double Throw Non-Fusible Safety Switch, 2 Pole, NEMA 3R Enclosure w/ Bolt on Hub Provision (240VAC, 250VDC), DTU223RB

Schneider Electric's Square D double throw safety switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. Double throw safety switches are designed for commercial, industrial, and manufacturing installations. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock, and a color coded indicator handle. This double throw safety switch is a non fusible disconnect and has a rated current of 100A for 240VAC and 250VDC. This heavy duty switch has a 2 wire configuration with 2 poles. The enclosure is surface mounted and is a Type 3R with bolt on provisions. All heavy duty safety switches are tested per UL98 and NEMA KS1 standards and are UL listed.

Features:

• Nema Rating: 3R
• Fused: No
• Number Of Poles: 2
• Amperage: 100
• Horsepower at 1 Phase: 15 at 240Vac
