4" Evolution Poke-Thru Device, Pre-Wired Dual Service, 4 Outlets (Black)

Designed for retrofit and new construction, Evolution Series 4” Poke-Thru devices provide convenient access to power, communications, and audio/video services recessed below floor level - providing maximum device protection. Two gangs of capacity allow you to configure services for the needs of your space. Evolution Series 4” Poke-Thru devices are the perfect fit for kiosks, training rooms, classrooms, healthcare facilities or commercial buildings with open-space architecture.

Features

Recessed Prewired Dual Service Surface Style Poke-Thru Assembly

Designed to be installed in concrete floors

Accessibility to ceiling space below floor is required to feed power, data and A/V services

Installs into a 4" (102mm) to a 4-1/8" (105mm) diameter hole

Unit comes complete with surface style cover, one (2) prewired,pre-installed duplex receptacle that is recessed 3-3/4" (95mm) below floor surface level and one (1) empty gang

Surface style cover is aluminum and is designed to sit on top of finished floor surfaces, including: carpet, tile, wood, polished concrete or terrazzo

Die-cast aluminum cover built to withstand demanding environments

intumescent material that maintains a fire rating of a 2-hour classified floor

Covers that open up a full 180°

Slide doors that keep wires, connections and people safe

Fully finished interior

Designed to accept audio/video devices from leading manufacturers

Devices recessed below floor level

Works with Pass & Seymour® Wireless RF receptacles to control plug loads up to a distance of 30 feet when the cover is closed

Included
Devices & Device Plates:

• (2) proprietary 20A Duplex Receptacle installed Bottom Feed:
  • (1) 3/4" trade size conduit stub, located below receptacle
