MANUALS (3)
Lift Gate
Product Highlights
Description
Specs
| Product Type: | Standard Grease Trap |
|---|---|
| Length (Inches): | 40-1/4" |
| Width (Inches): | 28-5/8" |
| Height (Inches): | 22-3/4" |
| Material: | Steel |
| Flow Rate (GPM): | 75 |
| Inlet Type: | No Hub |
| Capacity (lbs): | 150 lbs |
| Inlet Size: | 4" |
| Outlet Size: | 4" |
| Outlet Type: | No Hub |
| Application: | Plumbing |
Questions?
You May Also Need
Product Reviews
 --%3E %3Csvg version='1.1' id='With-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23FBC8B4' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
I probably will order from Supply House again in the future.
Item was as expected.
I would buy this product again and again
Product Q&A
4 QuestionsQ: Can this grease trap be installed 1 floor level down and where should the flow control be installed, up by the sink or down by the GT?
Asked by gt 14 years ago
Add your answer
Verified Reply- PexSupply StaffAccording to the manufacturer, if the interceptor is to be installed on the floor below the sinks or whatever else is supplying the interceptor, a few adjustments need to be made. First of all, it is recommended that 2 flow controls be installed. 1 at the top of the vertical drop and one on the horizontal pipe at the bottom of the drop. Second, we recommend that a stretch of horizontal pipe be used upstream of the interceptor but after the vertical drop to allow the water to slow down and become less turbulent after the drop. This horizontal pipe should at least be the length of the drop but will actually help the interceptor work more efficiently if it is longer than this.
Q: When this is installed below grade in Miami, The building or Health department requires unit to be inside a vault, any suggestions the vault needs to be lightweight and able to enter through a 3'0" x 7'0" door entrance, with a lid which can be walked on. any suggestions
Asked by Bill 14 years ago
Add your answer
Verified Reply- PexSupply StaffIt appears they require some sort of a concrete box around the grease trap, but you will likely need to check with a local official to get the specifics.
Q: can the inlets and outlets be reduced ?
Asked by 15 years ago
Add your answer
Verified Reply- PexSupply StaffYou may be able to reduce them, but it depends on your flow rate and the length of the run.
Q: Can this be installed below floor?
Asked by Big D 15 years ago
Add your answer
Verified Reply- PexSupply StaffYes; it can be installed below the floor, flush with the floor, or on top of the floor.
