Description


Features
  • Reliable, proven design with high flows
  • Small poppet valves for tight shutoff
  • Wide range of elastomers for specialty service
  • Mountable in any position
  • Brass and stainless steel constructions
  • Nominal Ambient Temp: Ranges AC: 32°F to 125°F (0°C to 52°C)
    DC: 32°F to 104°F (0°C to 40°C)

    Solenoid Enclosures
    • Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X
    • Optional: Explosion-proof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9
Read more
Manuals (1)
Specs
Size:
1/8"
Connection Type:
Threaded
Flow Capacity (Cv):
0.34
Voltage:
240v
Wattage:
10.6 (DC)
6.1 (AC)
Body Pattern:
2-Way
Max Fluid Temp:
120°F (DC)
180°F (AC)
Features:
NEMA 4X
Flow type:
High Flow
Position:
Normally Closed
Thread Type:
Female
Thread Size:
1/8"
Material:
Brass
Pressure Rating:
140 psi (Lt. Oil @ 300 SSU - MAX AC)
180 psi (Water - MAX AC)
155 psi (Air-Inert Gas - MAX AC)
80 psi (Water - MAX DC)
80 psi (Air-Inert Gas - MAX DC)
80 psi (Lt. Oil @ 300 SSU - MAX DC)
Application:
Plumbing
Voltage:
480v
Connection Type:
Threaded
Flow type:
High Flow
Ambient Temperature:
32°F to 125°F (AC)
32°F to 104°F (DC)
×
