Description


Features
  • Reliable, proven design with high flows
  • Small poppet valves for tight shutoff
  • Wide range of elastomers for specialty service
  • Mountable in any position
  • Brass and stainless steel constructions
  • Nominal Ambient Temp: Ranges AC: 32°F to 125°F (0°C to 52°C)
    DC: 32°F to 104°F (0°C to 40°C)

    Solenoid Enclosures
    • Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X
    • Optional: Explosion-proof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9
Hide Description
Manuals (1)
Specs
Size:

1/4"

Connection Type:

Threaded

Flow Capacity (Cv):

0.5

Voltage:

120v

Wattage:

10.1 (AC)

11.6 (DC)

Body Pattern:

2-Way

Max Fluid Temp:

180°F (AC)

150°F (DC)

Features:

NEMA 4X

Flow type:

High Flow

Position:

Normally Closed

Thread Type:

Female

Thread Size:

1/4"

Material:

Brass

Pressure Rating:

145 psi (Lt. Oil @ 300 SSU - MAX AC)

200 psi (Water - MAX AC)

180 psi (Air-Inert Gas - MAX AC)

40 psi (Air-Inert Gas - MAX DC)

40 psi (Water - MAX DC)

45 psi (Lt. Oil @ 300 SSU - MAX DC)

Application:

Plumbing

Voltage:

120v

Connection Type:

Threaded

Flow type:

High Flow

Ambient Temperature:

32°F to 125°F (AC)

32°F to 104°F (DC)

×
