Description
ASCO Valve's Fuel, Gas & Oil solenoid valves handle combustion system pilot & main line fuel shutoff & control needs. Our Fuel, Gas & Oli solenoid valves are available in 2-way normally closed, normally open, manual reset, and 3-way diversion. ASCO valves are available in brass, aluminum, and stainless steel. Features include junction box, pipe taps, visual indication, proof of closure, leading agency approvals, and pipe connections from 1/8" to 3". Most valves are rated for -40ºF service for outdoor installation in frigid climates.

Features:
  • 2-way normally closed operation
  • For gas pilot control of commercial and industrial gas burners
  • Direct lift with resilient soft seating for tight shutoff
  • Valves provided with 1/8" NPT downstream pipe tap with plug for routine testing
  • Suitable for ambient temperatures up to 175°F


Construction:
  • Body: Aluminum
  • Seals and Disc: NBR
  • Core Tube: 305 Stainless Steel
  • Core and Plugnut: 430F Stainless Steel
  • Springs: 17-7PH
  • Shading Coil: Copper
  • Pipe Plug: Zinc-Plated Steel

Read more
Specs
Capacity:
537000 BTU
Size:
1/8"
Connection Type:
Threaded
Voltage:
110/120v
Flow Capacity (Cv):
1
Wattage:
6.1
Body Pattern:
2-Way
Max Fluid Temp:
125°F (DC)
Flow type:
High Flow
Position:
Normally Closed
Thread Type:
Female
Thread Size:
1/4"
Material:
Aluminum
Application:
Plumbing
Voltage:
480v
Connection Type:
Threaded
Flow type:
High Flow
Ambient Temperature:
32°F to 125°F (AC)
32°F to 104°F (DC)
×
