HYLUG Two Hole Standard Barrel Copper Lug, Wire Size #2 AWG, 1/4" Bolt (Brown)

2 Flex G,H,I,K,M,DLO, 2 AWG CU, Two Hole, 1/4 Stud Size, 5/8 Hole Spacing, Standard Barrel, Inspection Window, Narrow Tongue, Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Brown Color Code, 10 Die Index.

Product Specifications

• Electro-tin plated unless otherwise specified to reduce galvanic corrosion (bimetallic) and resist corrosive elements
• Connectors are clearly marked with stamping and barrel color coding
• For applications greater than 2000 Volts consult cable manufacturer for voltage stress relief instructions
• Application: Wire Termination
• Color Code: Brown
• Connector Type: STANDARD BARREL
• Die Index: 10
• EU RoHS Indicator: Yes
• Feature - Barrel Style: Chamfered
• Feature - Barrel Type: Standard
• Finish Type: Tin-Plated
• Material: COPPER
• Physical Attribute - Number of Holes: 2
• Plated: Y
• Plating Type: Tin - Electro Plated
