80,000 BTU/Hr Low Pressure BPX Brazed Plate Heat Exchanger
 --%3E %3Csvg version='1.1' id='No-RB' xmlns='http://www.w3.org/2000/svg' xmlns:xlink='http://www.w3.org/1999/xlink' x='0px' y='0px' viewBox='0 0 100 100' enable-background='new 0 0 100 100' xml:space='preserve'%3E %3Cpath fill='%23CECECE' d='M79.44,0.95H20.56C9.78,0.95,0.95,9.78,0.95,20.56v58.87c0,10.79,8.82,19.61,19.61,19.61h58.87 c10.79,0,19.61-8.83,19.61-19.61V20.56C99.05,9.78,90.22,0.95,79.44,0.95z M65.38,58.24l9.38,29.58L49.69,69.78L24.5,87.82 l9.34-29.6L8.8,39.6l30.73-0.17c0,0,6.98-19.61,10-28.93c0.54,1.36,9.88,29.1,9.88,29.1H91.2L65.38,58.24z'/%3E %3C/svg%3E){kind=small}
Hover image to zoom
$720.69 each
In Stock
Order by 6PM, receive Tomorrow
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
12-1/5"
4-7/20" Depth
Male Thread Type
435 MAX PSI
-310°F - 450°F
-310°F Min Temp
Description
–
B & G type Low Pressure BPX brazed plate heat exchangers offer the highest level of thermal efficiency and durability in a compact, low cost unit. These are ideal for applications that require 150 PSIG or less. The corrugated plate design provides very high heat transfer coefficients, resulting in a more compact design. The unit's stainless steel plates are vacuum brazed together to form a durable, integral piece.
Technical Specifications:
Applications:
Outdoor Wood Boiler:
Technical Specifications:
- BTU/Hr: 80,000
- Design Pressure: 435 PSI
- Design Temperature: -310°F min, 450°F max
- Number of Plates: 20
- Channel Plates: Stainless Steel ASTM 316L
- Brazing Material: Copper
Applications:
Outdoor Wood Boiler:
- Boiler Side: Water 180 Degree F Supply, 155 Degree F Return, Flow: 6.6 GPM, Pressure Drop: 1.9 PSI
- House Side: Water 140 Degree F Supply, 165 Degree F Return, Flow: 6.5 GPM, Pressure Drop: 1.6 PSI
Specs
–
| Number of Plates: | 20 |
|---|---|
| Width: | 4-2/5" |
| Height: | 12-1/5" |
| Application: | Heating |
| Type: | Outdoor Wood Boiler |
| Depth (Inches): | 4-7/20" |
| Thread Type: | Male |
| Brazing Material: | Copper |
| Cover Plate Material: | Stainless Steel |
| Max Pressure (PSI): | 435 |
| Temperature Range (F): | -310°F - 450°F |
| Min Temp (F): | -310°F |
| Thread Size: | 1" |
