$1,840.70 each
In Stock
Get 8 Thu, Jun 11
Order by today, receive Thursday
MANUALS (2)
'/%3E%3C/svg%3E){kind=small}
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
115V
3/4 HP
32.9 MAX GPM
145 MAX PSI
Cast Iron
1-1/2" Connection
Description
–
Note: This circulator requires:
539605: 1-1/2" Cast Iron Flange Set (For UP43 Flange Mounted Pumps Only)
539605: 1-1/2" Cast Iron Flange Set (For UP43 Flange Mounted Pumps Only)
- Cast Iron
- GF 40/43 Flange Mount
- Model: UPS32-160/2
- Normal Flange Size (in.): 1.5"
- Motor HP: 3/4
- Voltages: 115
- PH: 1
Specs
–
| Frequency: | 60 Hz 60 Hz 60 Hz |
|---|---|
| Horse Power: | 3/4 |
| Application: | Zoning |
| Material: | Cast Iron |
| Voltage: | 115V |
| Max Pressure (PSI): | 145 |
| Type: | 3-Speed Pump |
| Max Flow (GPM): | 32.9 |
| Flow Range (GPM): | 0-32.9 |
| Max Head (Ft): | 52.5 |
| Head Range (ft.): | 0-52.5 |
| Phase: | 1 |
| Connection Size: | 1-1/2" |
| Mount: | In-Line |
Questions?
Speak with a real person who will go out of the way to help!
Call or text 888-757-4774
Monday – Thursday
8am–7:45pm
Friday
9am–7:45pm
Saturday – Sunday
9am–5:45pm
You May Also Need
3 Replacement Parts
Gasket Kit, 96406940
SKU: 96406940
GrundfosPump Head for UPS32-160/2, 1 PH, 115V
SKU: 96407079
Grundfos
Need help finding a replacement part?
Fill out the part request form and someone will get back to you shortly.
PART REQUEST FORM
Product Reviews
5 out of 4 reviews
100% would recommend this product
5 star
100%
4 star
0%
3 star
0%
2 star
0%
1 star
0%
Showing 1-4 of 4 reviews
I was happy with the pricing and timely delivery.
Everything was perfect.
Jason
Dickinson, ND
8 years ago
Verified Buyer
Was this review helpful to you?
Great Pump
Easy install and virtually no maintenance
Justin
Pine Bush, NY
10 years ago
Verified Buyer
Was this review helpful to you?
I would buy this product again
Easy to install. Easy to change speeds. Very dependable pump.
HVAC Mike
Oradell, NJ
10 years ago
Verified Buyer
Was this review helpful to you?
Have several of these in operation
For the most part I have been very happy with this pump. The last one I purchased is to replace an existing one that was only in for two years, unknown why it failed, but it happens. Several others are working fine for many years now. I like the multi-speed versatility of this pump.
Maintenance Gordon
Michigan
12 years ago
Verified Buyer
Was this review helpful to you?
Product Q&A
2 Questions2 Questions
Q: red light is on pump does not run. what needs to be replaced
Asked by clyde 11 years ago
Add your answer
Verified Reply- SupplyHouse StaffAs per the troubleshooting guide provided in the installation manual when the red light is on and the pump does not run then the pump has been cut out by the thermal over-load switch due to high liquid temperature or blocked rotor. They note to check that the liquid temperature falls within the specified range. The pump will restart automatically when it has cooled to normal temperature. NOTE: If the thermal overload switch has cut out the pump three times within a short period, the pump must be restarted manually by switching off the electrical supply.
Was this review helpful to you?
Q: Is this a 115 or 230 volt pump?
Asked by Mainman 14 years ago
Add your answer
Verified Reply- PexSupply StaffThis is a 115v pump.
