Description
The Q7002 Interface Modules allow controllers with an otherwise incompatible signal to control an Economizer Logic Module or Direct Coupled Actuator.

Features
  • 24 Vac or 24 Vdc power
  • Available for input signals: dc voltage, current, or resistive; and pulse-width modulation (PWM).
  • Available to provide output: analog voltage or current for an actuator.
  • Inputs and outputs are jumper-selectable and include adjustable zero and span.
  • Output is jumper-selectable direct or reverse acting.
  • Includes reference voltage and current to power an input device or sensor.
  • PWM time base is user-selectable with positive or negative input reference; all ranges have 255-step resolution.
  • Multiplex mode enables one PWM signal from a Building Automation System (BAS) controller to address and control up to eight interface modules.

Specifications
  • Description: Transducer, Accepts dc voltage, current, or resistive input and provides a voltage or current output
  • Supply Voltage: 24 Vac ±20%, 24 Vdc
  • Mounting: Enclosure (NEMA 1) with mounting tabs
  • Frequency: 60 Hz
  • Output Burden: 0 to 20 mA < 500 ohm; 0 to 10 Vdc > 500 Ohm
  • Comments: Input: dc voltage, current, or resistive, Output: voltage or current output
  • Used with: Direct-Coupled Proportional Actuators and Modutrol Motors
Read more
Manuals (1)
Specs
Product Type:
Interface Module
×
