$248.81 each
In Stock
Get 6 Tomorrow, Jul 8
Order by 6PM, receive Tomorrow
MANUALS (1)
This item replaces: T4054A1000
Free Shipping This item ships free
Easy Returns No restocking fee for 90 days
Product Highlights
–
120v, 240v
-30° to 110°F, 110°F Max Temp
-30°F Min Temp
3.5°F
7.25" Height
2" Depth
Description
–
Features:
Specifications:
- Provides SPDT heavy-duty, line-voltage temperature control in ventilation, heating or cooling systems.
- Use in a variety of farm, industrial or commercial applications.
- Wall or duct mount in any position.
- Fast response, tin-plated element not affected by adverse environment.
- Rugged case.
- Mounts on flat surface with three screws.
Specifications:
- Return Air Temperature Controller, -30 F to 110 F
- Application: Provides control in ventilation, heating, cooling or heating-cooling systems
- Type: Filled element
- Output Type: relay
- Output: 1 SPDT
- Voltage: 120 Vac or 240 Vac
- Frequency: 50, 60 Hz
- Sensor Element: Copper filled element
- Number of Sensor Inputs: 1
- Setpoint Temperature Range (F): -30 F to 110 F
- Maximum Operating Temperature (F): 125F
- Accuracy (F): +/- 10F
- Differential Temperature (F): 3.5F
Specs
–
| Application: | Commercial Return Air Temperature |
|---|---|
| Output: | SPDT Relay |
| Voltage: | 120v 240v |
| Hertz: | 50 60 |
| Contact Ratings 120v: | 7.4 AFL 44.4 ALR |
| Contact Ratings 240v: | 3.7 AFL 22.2 ALR |
| Height (Inches): | 7.25" |
| Width: | 2-5/8" |
| Depth (Inches): | 2" |
| Sensor Type: | Copper Filled Element |
| Sensor Inputs: | 1 |
| Max Operating Temp: | 125°F |
| Accuracy: | +/- 10°F |
| Differential: | 3.5°F |
| Min Temp (F): | -30°F |
| Max Temp (F): | -30° to 110°F 110°F |
| Color: | Gray |
