This R410A unit is no longer manufactured as per the AIM Act of 2020. While replacement parts are available for repairs, a new unit will require replacing the entire system to support the new A2L R32 refrigerant.
Please visit our Mini Split Air Conditioners for system selection or reach out to Customer Care Team Contact Us for assistance.
| Max. Pipe Length (ft.): | 65.6' |
|---|---|
| Cooling Capacity (BTU): | 11200 |
| Heating Capacity (BTU): | 13300 |
| Number of Zones: | 1 |
| Energy Star Rated: | Yes |
| SEER: | 21.5 |
| EER: | 12.5 |
| Application: | Heating Cooling |
| Refrigerant Type: | R-410A |
| Dehumidification (Pts/Hr): | 2.3 |
| Fan Speeds: | 6/6/6 |
| Modes: | Heating Auto Sleep Dehumidification Cooling Fan |
| Outdoor dB(A): | 45 |
| Indoor dB(A): | 39/33/23/19 |
| Air Circulation (CFM H/M/L): | 353/272/191 |
| Outdoor Voltage: | 230/208-60-1 |
| Indoor Voltage: | 230/208-60-1 |
| Liquid Line: | 1/4" |
| Suction Line: | 3/8" |
| Max. Elevation (ft.): | 32.8 |
| Connection Type: | Flare |
| Outdoor Dimensions (H x W x D): | 21-1/2" x 30-5/16" x 11-5/16" |
| Indoor Dimensions (H x W x D): | 11-1/4" x 34-7/8" x 8-1/4" |
| Indoor Weight: | 20 lbs |
| Outdoor Weight: | 75 lbs. |
| Thermostat Range (Cooling/Heating): | 64°-86°F/60°-86°F |
| Warranty: | 7 Year (Compressor)/5 Year (Parts) |
| Mount: | Wall |
