$37.09 each
Out of Stock
Get it Tue, Jul 21 - Tue, Jul 28
MANUALS (1)
Free Shipping On orders over $99
Easy Returns No restocking fee for 90 days
Product Highlights
–
20 Amps
Black
Nylon
Heavy-Duty Industrial
10 years Warranty
Description
–
Features
Specifications
- Reliable - 10-Year Limited Warranty
- Code Compliant - Allows you to increase the number of receptacles in your facility without having to pull new wires
- Leviton's line of Heavy-Duty Industrial Grade receptacles are available with a number of wiring options and features. The beauty, durability and versatility of Decora devices and surge supression receptacles are perfect for a variety of industrial applications.
- Easy Installation - Termination anchor holes for easy conductor wiring
- Durable - Impact and chemical resistant nylon cover and base
- 5-20R
Specifications
- Grade: Heavy-Duty Industrial Specification Grade
- Amperage: 20 A
- Wire: 3
- Color: Black
- Country of Origin: Mexico
- Operating Temperature: -40 °C to 60 °C
- ANSI: C-73
- CSA C22.2 No. 42: File 152105
- Terminal Accom.: 14-12 AWG
- Termination: Side Wire
- Flammability: Rated V-2 per UL 94
- Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current
- Torque Range: 12-14 inch pounds
- Warranty: 10-Year Limited
- RoHS Compliant: FALSE
- At Rated Voltage: 1 HP
- Current Limiting: Full Rated Current
- Strap Material: Galvanized Steel with Riveted Ground Contacts
- NEMA: WD-1 WD-6
- Grounding: Grounding
- Body Material: Nylon
- UL498: File E13399
- Voltage: 125 VAC
- Terminal Screws: Plated Brass
- Dielectric Voltage: Withstands 2000V per UL498
- Line Contacts: Phosphor Bronze
- Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
- Grounding Screw: Plated Steel
- Product ID: Ratings are permanently marked on device
- Face Material: Nylon
- Pole: 2
- NOM: 57
- Device Type: Quadruplex Receptacle Outlet
- Brand: 4-in-1
- Screw Terminal Torque: 10-12 in-lbs
Specs
–
| Amperage: | 20 |
|---|---|
| Terminations: | Side Wire |
| Series: | 4-in-1 |
| Color: | Black |
| Country of Origin: | Mexico |
| Product Type: | Quadruplex Receptacle |
| Material: | Nylon |
| NEMA Rating: | WD-6 WD-1 |
| Poles: | 2 |
| Grade: | Heavy-Duty Industrial |
| Warranty: | 10 years |
| Ground: | Grounding |
