Description
Features:
  • Solid State dependability
  • Replaces Honeywell and White-Rodgers
  • Ambient rated from 20°F. to 160°F.
  • Used on both separate blower and element and combination blower and element systems
  • Total 24 Volt control
  • Standard double quick-connect terminals for combination fan and element systems
  • Full-load-rated auxiliary contacts
  • 7.2 KW combination fan and element rated contacts (23A. resistive, 7A. motor load)
  • Non-positional
  • Voltage and ambient self compensating positive temperature coefficient (PTC) heater elements
  • Individually packaged with wiring diagrams for up to seven element furnaces.
  • UL and CSA listing available
Read more
Manuals (1)
Specs
Type:
Sequencer
Action:
DPST
Voltage:
24v
×
