MODA F1960 Expansion PEX Kitchen Supply Outlet Box w/ Hammer Arrestor

Moda Supply Box System is designed to meet the needs of plumbing contractors for washing machine, ice maker, lavatory, toilet, dishwasher and SureVentAir Admittance Valve applications. A universal single box platform provides maximum versatility, installation simplicity and rugged reliability. MODA Supply Box System is the ultimate solution for speed and flexibility.

Product Features

• MODA® compact-size kitchen outlet box
• Advanced snap-lock design allows for easy assembly/disassembly and connection to another MODA box
• Contains (3) 3/8 in. outer diameter compression valves pre-installed in two PVC boxes with interlocking wing flanges that accommodate on-stud, straddle-stud and three-box installation
• Dual box design features a supply box for dishwasher valves and a box for faucet valves
• Separate valve and drain boxes allow paired or split boxes between walls or stud bays to prevent supply/drain crossovers; valves rated to 150 PSI air and 250 PSI water
• Durable PVC box construction stands up to the roughest jobsite conditions
• Includes a tool-free quarter-turn test plug with gasket to prevent knock outs from falling down the drain pipe
• Box dimensions: 8 in. W x 4.85 in. H x 3.38 in. D; box opening dimensions: 3.82 in. W x 4.367 in. H
• Faceplate dimensions: 6 in. W x 6.45 in. H

Product Specifications>/b>

• Brand: Oatey
• Valve Size: 0.375 in.
• Color: White
• Material: PVC
• Valve Body Material: Chrome
• Connection Size: 0.50 in.
• Product Line: MODA
