Product Highlights
–
420v
Description
–
Features
- Temperature range: 40 °F to 130°F
- Class B insulation
- Continuous duty
- Depth (In.) 1.8
- Width (In.) 2
- Continuous Coil Voltage 420
- Pick-Up Min. 223
- Pick-Up Max. 252
- Drop Out Max. 150
- Coil Data DC Resistive 10000
- Coil Data Nom. VA 5
- Coil Data MA 12
- Coil Data Inrush VA 10
- Temperature Range ºF 40F-130F
- Class Insulation B
- Voltage 420
Specs
–
| Product Type: | Relay |
|---|---|
| Voltage: | 420v |
