Description
Features
  • Compact design
  • Reduced sound levels (from previous models)
  • DC fan motor for increased efficiency
  • Powerful drain pump gives 33-1/2 ft lift
  • Lightweight design
  • Fresh air knockout
  • Branch duct connection
A proprietary design features wide-angle discharge outlets and flaps that are larger in the middle, featuring a shape that was selected based on numerical mechanics and testing of actual prototype units. Air coming out of the center of the discharge outlets travels farther. From the sides of each outlet, where the openings are larger, airflow spreads out to reach the corners of the room. Air is discharged across a wide area from the four sides of the unit. The curves on the room temperature distribution graph expand gently out through 360° in a circle centered on the indoor unit.
Read more
Manuals (1)
Specs
Product Type:
Indoor Unit
Heating Capacity (BTU):
29000
SEER:
14.1
Moisture Removal:
8.1 pints/h
Cooling Capacity (BTU):
24800
Dry Air Flow (Hi/Med/Low CFM):
710/530/450
Refrigerant Pipe Type:
Flare
Operation Sound In.:
38/35/31
Programmability:
7 Days/6 Events
Liquid Line:
3/8"
Suction Line:
5/8"
Height:
13-5/16"
Depth (Inches):
33-55/64"
Width:
33-55/64"
Max. Pipe Length (ft.):
165'
×
