Description
Duct Fan, In-Line, 2 Speed Mixed Flow, Fits Duct Dia 12 In, CFM @ 0.000-In SP 1050/751, CFM @ 0.125-In SP 990/670, Max Inlet Temp 140 Deg F, Voltage 115, 60 Hz, Single Phase, Max Amps 2.3, Bearing Type Ball, Housing Dia 13 1/4 In, Length 14 In, Mounting Position Horizontal or Vertical, Includes Mounting Bracket.

Features:
  • Hz: 60
  • Bearing Type: Ball
  • Mounting Position: Horizontal or Vertical
  • Includes: Mounting Bracket
  • Phase: 1
  • Voltage: 115V
  • Motor Enclosure: Totally Enclosed
  • Item: Mixed Flow Duct Fan
  • Number of Speeds: 2
  • Speed Control: Mfr. No. 48C172
  • Housing Finish: Epoxy
  • CFM @ 0.000-In. SP: 1050/751
  • CFM @ 0.125-In. SP: 990/670
  • CFM @ 0.250-In. SP: 932/545
  • CFM @ 0.375-In. SP: 850/420
  • CFM @ 0.500-In. SP: 770/285
  • CFM @ 0.750-In. SP: 600/190
  • CFM @ 1.000-In. SP: 420/130
  • CFM @ 1.500-In. SP: 255/55
  • Max. Amps: 2.3
  • Max. Wattage: 335/208
  • Motor HP: 1/2
  • Motor RPM: 2500/2000
  • Housing Material: Metal
  • Fits Duct Dia.: 12"
  • Flange Width: 2"
  • Standards: C-UL-US
  • Max. Inlet Temp.: 140 Degrees F
  • Housing Dia.: 13-1/4"
  • Length: 14"
  • Inlet and Outlet Dia.: 12-1/4"

**Image may not be exact representation of product.**
Read more
Manuals (1)
Specs
Duct Size:
12.4"
Voltage:
115v
RPM:
2500
2000
Air Flow Capacity (CFM):
1050
751
Max. Watts:
335
208
Bearings:
Ball
Amperage:
2.3
Housing Material:
Metal
Warranty:
5 Year Limited Warranty
×
