SaniCONDENS Condensate Pump (White)

The Saniflo 040 SaniCONDENS is a compact, 1/30 HP condensate pump designed to remove acidic condensate from high-efficiency appliances when gravity drainage isn't feasible. It efficiently pumps condensate up to 15 feet vertically or 150 feet horizontally, making it suitable for both residential and commercial applications.

Key Features

• Motor: 1/30 HP oil-filled, thermally protected
• Voltage: 120V, 60Hz
• Amperage: 1.5 A
• Max operating temperature: 160°F
• Noise level: (_<) 44 dBA at 3 ft
• Discharge rate: 86 GPH at 3 ft; 30 GPH at 15 ft
• Discharge pipe diameter: 3/8"
• Tank capacity: 0.5 gallons (1.9 liters)
• Dimensions: 9-1/2" L x 5-5/8" W x 6-5/8" H
• Weight: 7 lbs
• Includes 20 ft of vinyl tubing, inlet adapter, and discharge adapter
• Built-in non-return valve on discharge connection
• Provision for ready-to-wire connection to an external overflow switch
• 2-year warranty

Compatibility & Applications

• Condensing boilers
• HVAC systems
• Water heater systems
• Air conditioners
• Suitable for installations where gravity drainage is not possible

Installation & Operation Notes

• Activated by internal float mechanism
• Discharges condensate through a 3/8" vinyl tube
• Includes a non-return valve to prevent re-activation
• Power cord length: 60 inches

Maintenance & Troubleshooting

• Regular inspection recommended to ensure optimal performance
• Minimal maintenance due to sealed motor and limited moving parts
• Ensure vent system remains unobstructed for optimal performance

Certifications & Compliance

• UL 788 certified
• CSA C22.2 certified
