Product Highlights
Description
Ultra98 A2L Whole House High-Efficiency Ventilating Dehumidifier
The Santa Fe Ultra98 is designed to deliver exceptional indoor air quality by providing dedicated moisture control, fresh air mechanical ventilation and superior air filtration (MERV-13) to the entire home. The unit features an extremely well-insulated, compact horizontal cabinet (optional vertical discharge) for the ultimate in quiet operation.
Optional fresh outdoor air may be ducted to the unit. This provides fresh air to dilute pollutants and maintain high oxygen content in the air. The amount of fresh air ventilation can be regulated by a variety of dampers and controls.
Product Features
- Features a horizontal configuration with optional vertical discharge
- Designed for quiet operation
- Engineered for low temperature operation providing comfort year round
- Use of DEH 3000/R digital control for outdoor air ventilation and humidity control
- Superior MERV-13 filtration to improve indoor air quality
- Ducting option for fresh outdoor air ventilation
- Push button reset for transformer protection
Product Dimensions
- W: 14.5"
- H: 19.5"
- D: 32.38"
- Weight: 81. lbs.
Specs
| Air Flow Capacity (CFM): | 320 |
|---|---|
| Wattage: | 670 |
| Coverage (Sq Ft.): | 2300 |
| Noise Level (dBA): | 47 |
| Refrigerant Type: | R-454B |
| Product Type: | Dehumidifier |
| Capacity (Pints/Day): | 98 |
| Voltage: | 120v |
| Hertz: | 60 |
| Warranty: | 6 Year |
| Phase: | 1 |
| Current (amps): | 5.9 |
| Type: | Whole House |
| Operating Temp Range: | 49°F to 95°F |
| Energy Factor: | 2.95 L/kWh |
Questions?
Product Reviews
Happy with performance and ease of installation
