Harmony Pump Control Relay (5A, 1 CO, 208-480 VAC)

This Harmony RM35-BA control relay allows monitoring of pump control. This modular pump control relay is ideal for monitoring of electrical values in industrial and building control panels. It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water. It has one of market medium form-factors with 35mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 3-pole DIN device. It also offers a selectable memory function, integral LED for indicating control status, sealable cover, with simple and precise settings with screw trimmers. It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting. Multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC. 0 0 0 0 0 0 0 0 0 0 0 0

• Maximum Switching Current: 5 A AC/DC
• China Rohs Regulation: X
• Ambient Air Temperature For Storage: -40-70 °C
• Operating Rate: <= 360 operations/hour full load
• Ambient Air Temperature For Operation: -20-50 °C
• Nominal Output Current: 0.208333333333333
• Immunity To Microbreaks: 500 ms
• Measurement Accuracy: +/- 10 % of the full scale value
• Maximum Power Consumption In Va: 5 VA AC
• Control Circuit Voltage Limits: 15 % + 10 % Un
• Insulation Resistance: > 500 MOhm 500 V DC between supply and relay output 60255-5 || > 500 MOhm 500 V DC between measurement and relay output 60664-1 || > 1 MOhm 500 V DC between supply and measurement 60255-5 || > 500 MOhm 500 V DC between supply and relay output 60664-1 || > 500 MOhm 500 V DC between measurement and relay output 60255-5 || > 1 MOhm 500 V DC between supply and measurement 60664-1
• Mechanical Durability: 30000000 cycles
• Measurement Range: 1...10 A AC
• Electrical Durability: 100000 cycles
• Measurement Error: 1 % by volt over the whole range || +/- 0.05 %/°C
• Product Specific Application: for 3-phase and single-phase pump
• Minimum Switching Current: 10 mA 5 V DC
• Hysteresis: 5-5 % threshold
• Sustainable Offer Status: Green Premium product
• Switching Capacity In Va: 1250 VA
• Rohs Exemption Information: Yes
• Status Led: 1 LED Green power ON || 1 LED Yellow fault || 1 LED Yellow relay ON
• Product Or Component Type: pump control relay
• Repeat Accuracy: +/- 1 % input and measurement circuit || +/- 1 % time delay
• Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Range Of Product: Harmony Control Relays
• Relay Monitored Parameters: overcurrent and undercurrent control || phase sequence on 3-phase supply || phase failure on 3-phase supply
• Electromagnetic Compatibility: emission standard for industrial environments IEC 61000-6-4 || emission standard for residential, commercial and light-industrial environments IEC 61000-6-3 || immunity for industrial environments NF EN/IEC 61000-6-2
• Width: 35 mm
• Connections - Terminals: screw terminals, 1 x 0.5...1 x 4 mm squared AWG 20...AWG 11) solid without cable end || screw terminals, 2 x 0.5...2 x 2.5 mm squared AWG 20...AWG 14) solid without cable end || screw terminals, 1 x 0.2...1 x 2.5 mm squared AWG 24...AWG 12) flexible with cable end || screw terminals, 2 x 0.2...2 x 1.5 mm squared AWG 24...AWG 16) flexible with cable end
• Environmental Disclosure: ENVPEP1504008EN
• Reset Time: 2000 ms
• Marking: CE : EMC 89/336/EEC || CE : 73/23/EEC
• Response Time: < 300 ms (in the event of a fault)
• Vibration Resistance: 0.35 mm 5-57.6 Hz)IEC 60068-2-6/IEC 60255-21-1 || 1 gn 57.6-150 Hz)IEC 60068-2-6/IEC 60255-21-1
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• Circularity Profile: ENVEOLI1504008EN
• Circularity Profile: ENVEOLI1504008EN
• Warranty: 18 months
• Product Certifications: C-tick || CSA || GOST || UL || GL
• Relay Name: RM35BA
• Tightening Torque: 0.6-1 N.m IEC 60947-1
• Output Contacts: 1 C/O
• Resistance Across Terminals: 0.01 Ohm E1-L2 terminals
• Operating Position: any position
• Housing Material: self-extinguishing plastic
• Standards: IEC 60255-6
• [Ui] Rated Insulation Voltage: 400 V IEC 60664-1
• Relay Type: pump control relays
• Ip Degree Of Protection: IP20 IEC 60529 terminals) || IP30 IEC 60529 casing)
• Dielectric Strength: 2 kV AC 50 Hz shock wave 4 kV)
