NEMA Combination Starter, Nonfusible Disconnect (Size 1, 27A, 10HP at 600VAC, 3 Phase, NEMA 1), 8538SCG11V02S

Type S nonreversing fusible combination starters are for motor control applications. Combination starters combine the requirements for motor overload and short circuit protection into one package. NEMA Size 1 starters have ratings of up to 7.5 HP at 208 and 240 VAC three phase and 10 HP at 480 and 600 VAC three phase. This is a nonfusible combination starter. This 3 pole starter is for three phase applications. Combination starters are available with a wide variety of replaceable coil voltages. Starter has a 110/120 VAC 50/60 Hz operating coil wired for separate control. This nonreversing NEMA combination starter has a melting alloy type overload relay which uses Type B thermal units to sense over current conditions. A painted sheet steel NEMA 3R/12 Dusttight and driptight industrial enclosure is used to protect this starter. Enclosure is 24.00 inches tall, 9.50 inches wide and 8.34 inches deep. A wide variety of accessories are available for Type S starters. Type S combination starters are UL listed and CSA certified.

Features:

• Continuous Amperage: 27
• Starter Type: NEMA
• Enclosure Type: Enclosed
• Compatible Motor Phase: Three Phase
• Action: NonReversible
